View In:   ArcGIS Online Map Viewer

Name: Annexations

Display Field: NAME

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>This layer contains information for locating past and present legal city boundaries within Los Angeles County. The Los Angeles County Department of Public Works provides the most current shapefiles representing </SPAN><A href="http://egis3.lacounty.gov/dataportal/2013/06/11/city-annexations/" STYLE="text-decoration:underline;"><SPAN>city annexations</SPAN></A><SPAN>and </SPAN><A href="http://egis3.lacounty.gov/dataportal/2013/01/03/city-boundaries/?utm_source=rss&amp;utm_medium=rss&amp;utm_campaign=city-boundaries" STYLE="text-decoration:underline;"><SPAN>city boundaries</SPAN></A><SPAN>on the Los Angeles County GIS Data Portal. The Department also provides large format city annexation maps (pdf) on its </SPAN><A href="ftp://dpwftp.co.la.ca.us/pub/mpm/SDU-GIS/City%20Annexations" STYLE="text-decoration:underline;"><SPAN><SPAN>FTP site</SPAN></SPAN></A><SPAN>. True, legal boundaries are only determined on the ground by surveyors licensed in the State of California. Numerous records are freely available at the </SPAN><A href="http://dpw.lacounty.gov/apps/survey/landrecords/" STYLE="text-decoration:underline;"><SPAN>Land Records Information</SPAN></A><SPAN>website, hosted by the Department of Public Works.</SPAN></P><P><SPAN>Principal attributes include:</SPAN></P><P><SPAN STYLE="font-weight:bold;">NO: </SPAN><SPAN>corresponds with numbers on the tables displayed on City Annexation Maps.</SPAN></P><P><SPAN STYLE="font-weight:bold;">ANNEX_No: </SPAN><SPAN>is a text version of the "NO" field listed above. Because this field is only used for the Long Beach and Los Angeles Annexation Maps, this value is null for all other cities.</SPAN></P><P><SPAN STYLE="font-weight:bold;">NAME</SPAN><SPAN>: is the official name under which the annexation was filed.</SPAN></P><P><SPAN STYLE="font-weight:bold;">TYPE: </SPAN><SPAN>is used to indicate which legal action occurred.</SPAN></P><UL><LI><P><SPAN STYLE="font-weight:bold;">A </SPAN><SPAN>- represents an Annexation to that city.</SPAN></P></LI><LI><P><SPAN STYLE="font-weight:bold;">D </SPAN><SPAN>- represents a Detachment from that city.</SPAN></P></LI><LI><P><SPAN STYLE="font-weight:bold;">V </SPAN><SPAN>- is used to indicate the annexation was rendered Void or withdrawn before an effective date could be declared.</SPAN><SPAN /></P></LI><LI><P><SPAN STYLE="font-weight:bold;">33 </SPAN><SPAN>- Some older city annexation maps indicate a city boundary declared 'as of February 8, 1933'.</SPAN></P><P><SPAN /></P></LI></UL><P><SPAN STYLE="font-weight:bold;">ANNEX_AREA: </SPAN><SPAN>is the land area annexed or detached, in square miles, per the recorded legal description.</SPAN></P><P><SPAN STYLE="font-weight:bold;">TOTAL_AREA:</SPAN><SPAN>is the cumulative total land area for each city, arranged chronologically.</SPAN></P><P><SPAN STYLE="font-weight:bold;">SHADE: </SPAN><SPAN>is used by some of our cartographers to store the color used on printed maps.</SPAN></P><P><SPAN STYLE="font-weight:bold;">INDEXNO: </SPAN><SPAN>is a matching field used for retriving documents from our department's document management system.</SPAN></P><P><SPAN STYLE="font-weight:bold;">STATE (Secretary of State): </SPAN><SPAN>Date filed with the Secretary of State.</SPAN></P><P><SPAN STYLE="font-weight:bold;">COUNTY (County Recorder): </SPAN><SPAN>Date filed with the County Recorder.</SPAN></P><P><SPAN STYLE="font-weight:bold;">EFFECTIVE (Effective Date):</SPAN><SPAN>The effective date of the annexation or detachment.</SPAN></P><P><SPAN STYLE="font-weight:bold;">CITY: </SPAN><SPAN>The city to which the annexation or detachment took place.</SPAN></P><P><SPAN STYLE="font-weight:bold;">FEAT_TYPE: </SPAN><SPAN>contains the type of feature each polygon represents:</SPAN></P><UL><LI><P><SPAN STYLE="font-weight:bold;">Land </SPAN><SPAN>- Use this value for your definition query if you want to see only land features on your map.</SPAN></P></LI><LI><P><SPAN STYLE="font-weight:bold;">Water </SPAN><SPAN>- Polygons with this attribute value represent internal navigable waters. Examples of </SPAN><SPAN STYLE="font-style:italic;">internal waters </SPAN><SPAN>are found in the Long Beach Harbor.</SPAN></P></LI><LI><P><SPAN STYLE="font-weight:bold;">3NM Buffer </SPAN><SPAN>- Per the Submerged Lands Act, the seaward boundaries of coastal cities and unincorporated county areas are three nautical miles (a nautical mile is 1852 meters) from the coastline.</SPAN></P></LI></UL></DIV></DIV></DIV>

Service Item Id: 8ebb29b9f6f94f7c8ee2fb60ecb8f8ce

Copyright Text: This data is maintained by the Los Angeles County Department of Public Works. Contacts: Elmer Carlos, 626-458-7104, ecarlos@dpw.lacounty.gov; John Hickok, 626-458-7355, jhickok@dpw.lacounty.gov; Thierno Diallo, 626-458-6920, tdiallo@dpw.lacounty.gov; Marianne Jeffers, PLS, 626-458-7113, mjeffers@dpw.lacounty.gov

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 6464018.999991134
YMin: 2052054.1248419732
XMax: 6580105.000102133
YMax: 2102433.5001328886
Spatial Reference: 102645  (2229)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [249, 214, 252, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• NO ( type: esriFieldTypeInteger, alias: NO, editable: true, nullable: true, defaultValue: null, modelName: NO )
• TYPE ( type: esriFieldTypeString, alias: TYPE, editable: true, nullable: true, length: 3, defaultValue: null, modelName: TYPE )
• ANNEX_AREA ( type: esriFieldTypeDouble, alias: ANNEX_AREA, editable: true, nullable: true, defaultValue: null, modelName: ANNEX_AREA )
• TOTAL_AREA ( type: esriFieldTypeDouble, alias: TOTAL_AREA, editable: true, nullable: true, defaultValue: null, modelName: TOTAL_AREA )
• SHADE ( type: esriFieldTypeInteger, alias: SHADE, editable: true, nullable: true, defaultValue: null, modelName: SHADE )
• INDEXNO ( type: esriFieldTypeString, alias: INDEXNO, editable: true, nullable: true, length: 50, defaultValue: null, modelName: INDEXNO )
• STATE ( type: esriFieldTypeDate, alias: STATE, editable: true, nullable: true, length: 8, defaultValue: null, modelName: STATE )
• COUNTY ( type: esriFieldTypeDate, alias: COUNTY, editable: true, nullable: true, length: 8, defaultValue: null, modelName: COUNTY )
• EFFECTIVE ( type: esriFieldTypeDate, alias: EFFECTIVE, editable: true, nullable: true, length: 8, defaultValue: null, modelName: EFFECTIVE )
• CITY ( type: esriFieldTypeString, alias: CITY, editable: true, nullable: true, length: 100, defaultValue: null, modelName: CITY )
• REMARKS ( type: esriFieldTypeString, alias: REMARKS, editable: true, nullable: true, length: 250, defaultValue: null, modelName: REMARKS )
• NAME ( type: esriFieldTypeString, alias: NAME, editable: true, nullable: true, length: 100, defaultValue: null, modelName: NAME )
• ANNEX_No ( type: esriFieldTypeString, alias: ANNEX_No, editable: true, nullable: true, length: 15, defaultValue: null, modelName: ANNEX_No )
• FEAT_TYPE ( type: esriFieldTypeString, alias: FEAT_TYPE, editable: true, nullable: true, length: 16, defaultValue: null, modelName: FEAT_TYPE )
• SC ( type: esriFieldTypeString, alias: SC, editable: true, nullable: true, length: 10, defaultValue: null, modelName: SC )
• ANNEX_TYPE ( type: esriFieldTypeString, alias: ANNEX_TYPE, editable: true, nullable: true, length: 30, defaultValue: null, modelName: ANNEX_TYPE )
• URL ( type: esriFieldTypeString, alias: URL, editable: true, nullable: true, length: 100, defaultValue: null, modelName: URL )
• created_us ( type: esriFieldTypeString, alias: created_us, editable: true, nullable: true, length: 254, defaultValue: null, modelName: created_us )
• created_da ( type: esriFieldTypeDate, alias: created_da, editable: true, nullable: true, length: 8, defaultValue: null, modelName: created_da )
• last_edite ( type: esriFieldTypeString, alias: last_edite, editable: true, nullable: true, length: 254, defaultValue: null, modelName: last_edite )
• last_edi_1 ( type: esriFieldTypeDate, alias: last_edi_1, editable: true, nullable: true, length: 8, defaultValue: null, modelName: last_edi_1 )
• COLOR_CODE ( type: esriFieldTypeInteger, alias: COLOR_CODE, editable: true, nullable: true, defaultValue: null, modelName: COLOR_CODE )
• COLOR_EGIS ( type: esriFieldTypeString, alias: COLOR_EGIS, editable: true, nullable: true, length: 50, defaultValue: null, modelName: COLOR_EGIS )
• Shape__Area ( type: esriFieldTypeDouble, alias: Shape.STArea(), editable: false, nullable: false, defaultValue: null, modelName: Shape.STArea() )
• Shape__Length ( type: esriFieldTypeDouble, alias: Shape.STLength(), editable: false, nullable: false, defaultValue: null, modelName: Shape.STLength() )

Templates:

• Name: Annexations
  Description:
  Prototype:
  COLOR_EGIS: null
  COLOR_CODE: null
  NO: null
  TYPE: null
  ANNEX_AREA: null
  TOTAL_AREA: null
  SHADE: null
  INDEXNO: null
  STATE: null
  COUNTY: null
  EFFECTIVE: null
  CITY: null
  REMARKS: null
  NAME: null
  ANNEX_No: null
  FEAT_TYPE: null
  SC: null
  ANNEX_TYPE: null
  URL: null
  created_us: null
  created_da: null
  last_edite: null
  last_edi_1: null

  Drawing Tool: esriFeatureEditToolPolygon

Capabilities: Query,Create,Update,Delete,Uploads,Editing

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: false

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Supported Operations:   Query   Query Attachments   Query Analytic   Apply Edits   Add Features   Update Features   Delete Features   Calculate   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
